Our Capablities

Jyothi NX4222

NX4222
Max. Load on Table 37100 Kg
X – Axis Travel 4200 mm
Y – Axis Travel 2760 mm
Z – Axis Travel 800 mm
Spindle Speed 10,000 rpm
Rapid 40 m/min
Cutting Feed 15 m/min
Control SIEMENS
No. of Tools (ATC) 40 Nos.
Table Size 3500 × 2000 mm

Jyoti VMC RDX 20 With 5th Axis

RDX-20
Max. Load on Table 400 Kg
X – Axis Travel 820 mm
Y – Axis Travel 510 mm
Z – Axis Travel 510 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1000 x 530 mm

BFW Xtron 544+ With 4th Axis

BFW XTRON 544+ With 4th Axis
Max. Load on Table 250 Kg
X – Axis Travel 500 mm
Y – Axis Travel 450 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 600×450 mm

BFW BMV 50TC With 4th Axis

RDX-20
Max. Load on Table 400 Kg
X – Axis Travel 800 mm
Y – Axis Travel 550 mm
Z – Axis Travel 550 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1000×510 mm

Jyoti VMC RX 20 With 4th Axis

RX-20
Max. Load on Table 400 Kg
X – Axis Travel 820 mm
Y – Axis Travel 510 mm
Z – Axis Travel 510 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1000 x 530 mm

Jyoti VMC 1260 nvu

RDX-20
Max. Load on Table 800 Kg
X – Axis Travel 1200 mm
Y – Axis Travel 600 mm
Z – Axis Travel 600 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1400 x 600 mm

BFW Chakra BMV 60+

Bfw Chakra BMV 60+
Max. Load on Table 400 Kg
X – Axis Travel 1050 mm
Y – Axis Travel 610 mm
Z – Axis Travel 610 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1200×650 mm

Global VMC 800

GLOBAL-VMC-800
Max. Load on Table 400 Kg
X – Axis Travel 800 mm
Y – Axis Travel 550 mm
Z – Axis Travel 550 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1000×550 mm

Yantrang VX 500

Yantrang VX 500
Max. Load on Table 400 Kg
X – Axis Travel 500 mm
Y – Axis Travel 400 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 15 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 800 x 400 mm

Jyoti Turning DX-200

Jyoti Turning DX-200
Max. Load on Table 250 Kg
X – Axis Travel 250 mm
Z – Axis Travel 300 mm
Chuck Dia 170 mm
Spindle Speed 4,000 rpm
Rapid 24 m/min
Cutting Feed 5 m/min
Control FUNUC
No. of Tools Turret 8 Nos.
Spindle A2-5

BMTC-45

BMTC-45
Max. Load on Table 250 Kg
X – Axis Travel 500 mm
Y – Axis Travel 450 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 600×450 mm
